【BRM-WSD】Micron Diamond Powder for Diamond Wire

Characteristics: Produced by specialized technique with premium grade MBD diamond raw materials, high strength, regular crystal shape, highly concentrated particle size distribution & effective particles, strictly control of rod-like and flaky shape particle, low impurity, high cutting efficiency of good sharpness, prominent dispersity and wear resistance.
Applications: Make diamond wire for dicing & slicing monocrystalline silicon, polycrystalline silicon, sapphire, LCD, magnetic materials, semiconductor materials, also used for other premium diamond grinding & polishing tools.
Available Coatings: Chemical Ni coating, Electroplated Ni coating, Ti-Ni composite coating, customized coatings are also available. (Nickel coating can greatly enhance the retention between diamond particles and core wire.)
Product Catalog: DiamondPowder Catalog.pdf

Send Email

Free Trial

【BRM-WSD】Micron Diamond Powder for Diamond Wire Description

Diamond wire saw made of diamond powder is also a wire saw that the diamond powder is fixed on the steel wire substrate by nickel coating. However, there is a metal carbide coating on the surface of the diamond powder, which refers to titanium carbide, tungsten carbide or chromium carbide.

A metal layer is deposited on a metal carbide coating on the surface of diamond powder. The metal of the metal layer is Ni or Cu, which is composed of diamond powder with a metal carbide-metal composite coating on the surface of the metal carbide coating. The wire saw matrix of the invention combines firmly with diamond powder, and the number of diamond usage increases significantly. Diamond has high cutting edge height and strong cutting ability. The sawing line speed and feed speed are significantly improved compared with the traditional method, and the diamond production efficiency is greatly improved.

Avaliable Sizes:
Micron Diamond Powder for Diamond Wire /BRM-WSD

0-0.25	0-0.5	0-1	1-2	2-4	3-6	4-8
✓	✓	✓	✓	✓	✓	✓
5-10	6-12	7-14	8-12	8-16	10-20	15-25
✓	✓	✓	✓	✓	✓	✓
20-30	22-36	30-40	20-40	36-54	40-50	40-60
✓	✓	✓	✓	✓	✓	✓
